VX200 - 1/2" Floor Standing

The VX200 is based on the original VX202 Quarter Inch Mixer, however is somewhat uprated, running on a 100% larger bore for greater delivery and efficiency along longer pipe lengths. Running two ½" bore pumps, this unit can mix anti-freeze and water for you at 77.3 litres per minute. Coupled with a full Varimix pipe work install from Air Pumping, mixed fluid can be dispensed at any position of your given choice.

If you would like to find out more information on our current units, please check the link at the top of the page where we still have detailed info on the classic series units. We are always happy to hear from our clients to, whether it's for enquiries or support - just give us a call!

Pump Models: 2 x ½" APA05/PS
Pump Materials: Polypropylene, Santoprene
Varimix Materials: Fibre Glass, Polypropylene
System Weight (Dry): 77.2 lbs (35 kgs)
System Weight (Full): 531.2 lbs (241 kgs)
Max. Flow Rate: 17 gpm (77.3 lpm)
Max. Suction Lift: 10 ft / 6 mtr s(Dry)
Max. Output per Cycle: 0.062 gallons (0.24 litres)
Max. Particle Size: 3/32" (2.4 mm)
Max. Temp. Limits: 35°f - 150°f (2°c - 66°c)
Unit Dimensions: 1270mm x 660mm x 660mm 50" x 26" x 26")
Noise Levels @ 70psi: 71.1 db (A)
